The PIC100K200 100kW 200kWh Solar-Storage-Diesel Intelligent Energy Cabin is a modular hybrid power system designed to replace traditional diesel generators in off-grid, remote, and emergency scenarios. Integrating a 200.704kWh long-life LFP battery (6000+ cycles) with high-efficiency solar charging and diesel backup, it delivers stable power while reducing operational costs and environmental impact.
Key Advantages:
Hybrid Power Flexibility: Combines solar, battery storage, and diesel generation for 24/7 energy reliability, ideal for areas with inconsistent grid access .
Extreme Environment Ready: Operates in -25℃~60℃ with IP55 protection against dust, salt spray, and water jets, ensuring durability in harsh climates .
Smart Management: Equipped with CAN/Ethernet/485 communication for remote monitoring, load balancing, and microgrid integration, enabling real-time energy optimization .
Low Noise & High Efficiency: <78dB operation (30% quieter than diesel gensets) and 98% MPPT tracking efficiency minimize disturbances and maximize solar energy capture .
Rapid Deployment: Cabin design mimics diesel generator dimensions for easy transportation and installation, reducing adaptation costs for industrial and commercial users .
